Round LED Downlight 18-24W Ø200mm Sensor 4CCT OSRAM Chip

The 24W Circular Sensor Plate 4CCT OSRAM is a recessed downlight with a programmable motion sensor, an OSRAM chip, selectable power and 4 colour temperatures, ideal for automatic lighting in garages, hallways and common areas.

General information about 24W Circular Sensor Plate 4CCT OSRAM

Its power is selectable between 18W, 20W, 22W and 24W, delivering 2250 to 3000 lumens with a 125 lm/W efficacy, an SMD2835 OSRAM chip and a CRI of 85. It offers 4 selectable colour temperatures: 2700K, 3000K, 4000K and 6000K. It includes a No Flicker driver.

It integrates an infrared motion sensor with a programmable hold time (15 s, 45 s or 5 min) and a 6 m range. 120° beam and Ø225 mm recessed format (Ø200 mm cut-out).

Use and application of 24W Circular Sensor Plate 4CCT OSRAM

It is ideal for garages, storerooms, hallways, entrance halls, stairs and common areas where automatic switch-on brings convenience and savings.

The sensor turns the light on when it detects movement and holds it for the set time before switching off.

Key benefits of 24W Circular Sensor Plate 4CCT OSRAM

• Programmable motion sensor (15 s / 45 s / 5 min), 6 m range.
• Selectable power 18 / 20 / 22 / 24W.
• 4CCT: 2700K / 3000K / 4000K / 6000K.
• SMD2835 OSRAM chip, CRI 85, 125 lm/W.
• No Flicker driver included, Ø200 mm cut-out.
• 40,000-hour service life and a 3-year warranty.

Featured specifications of 24W Circular Sensor Plate 4CCT OSRAM

Power: 18 / 20 / 22 / 24W selectable; Luminous flux: 2250-3000 lm; Efficacy: 125 lm/W; Chip: SMD2835 OSRAM; CRI: 85; Colour temperature: 2700K / 3000K / 4000K / 6000K (4CCT); Angle: 120°; Sensor: infrared motion, 6 m, programmable 15s/45s/5min; Driver: No Flicker, included; Service life: 40,000 h; Outer diameter: Ø225 mm; Cut-out: Ø200 mm; Certifications: CE and RoHS; Warranty: 3 years.

Installation and maintenance of 24W Circular Sensor Plate 4CCT OSRAM

Make a Ø200 mm hole, select the power, tone and sensor time, and connect the driver in line with electrical regulations. Always switch off the power before any work.

It needs no maintenance beyond an occasional clean. Specialised LED lighting distribution in Spain, with CE and RoHS certification and a professional 3-year warranty. Estimated delivery in 24h subject to stock availability. Check price and availability here.

Frequently asked questions about 24W Circular Sensor Plate 4CCT OSRAM

Does it have a sensor? — Yes, an infrared motion sensor, programmable with a 6 m range.

Can I choose power and tone? — Yes, 18-24W and 4 tones (2700K to 6000K).

How much light does it give? — 2250 to 3000 lm (125 lm/W).

What hole does it need? — A Ø200 mm cut-out.

What warranty does it carry? — 3 years.
