LED Floodlight ATEX 200W 120° IP66 LUMILEDS Chip MEAN WELL

The LED Floodlight ATEX 200W is a high-power industrial floodlight designed to safely light large areas in explosive atmospheres. With 22,000 lumens, a 120° optic and IP66 rating, it complies with the ATEX Directive 2014/34/EU and is suitable for zones 1, 2, 21 and 22.

General information about the LED Floodlight ATEX 200W

Built in aluminium with WF2 anti-corrosion treatment and IP66/IK10 protection, it integrates a Lumileds 3030 chip and a high-end Mean Well driver for stable, long-lasting operation. Its ATEX marking II GD Ex db eb mb IIC T6 Gb, Ex tb IIIC T80°C Db certifies use in flammable gas and dust atmospheres.

It delivers 22,000 lm with an efficacy of 110 lm/W, 6000K colour temperature (cool white), 0.95 power factor and 85-265V input. It replaces 400-500W metal-halide floodlights and lasts up to 50,000 hours.

Use and application of the LED Floodlight ATEX 200W

It is the ideal solution for refineries, chemical plants, loading docks, industrial yards and warehouse facades with dust or gas presence. Its 120° optic lights large areas evenly at height.

It works in a thermal range of -20°C to +40°C and its adjustable bracket makes it easy to aim the beam at the work area, drastically cutting the electricity bill versus traditional technology.

Key benefits of the LED Floodlight ATEX 200W

• ATEX certification for zones 1, 2, 21 and 22.
• 22,000 real lm with 110 lm/W efficacy.
• Lumileds 3030 chip and highly reliable Mean Well driver.
• IP66 and IK10 protection against dust, water and impacts.
• Aluminium body with WF2 anti-corrosion treatment.
• 50,000-hour lifespan with low maintenance.

Highlighted specifications of the LED Floodlight ATEX 200W

Power: 200W; Luminous flux: 22,000 lm; Efficacy: 110 lm/W; Colour temperature: 6000K; Beam angle: 120°; Protection: IP66 / IK10; Chip: Lumileds 3030; Driver: Mean Well; Voltage: 85-265V; Power factor: 0.95; Dimensions: 370 x 300 x 250 mm; Lifespan: 50,000 h; Warranty: 5 years.

Installation and maintenance of the LED Floodlight ATEX 200W

It is surface-mounted with its adjustable bracket. Before any work, disconnect the power supply and check that the cable glands are properly sealed to keep the IP66 rating and ATEX safety.

200W ATEX floodlight, IP66/IK10, with Lumileds chip and Mean Well driver.

Distributed in Spain by Ibérica de Iluminación, with a 5-year warranty, ATEX and RoHS certification and estimated 24h shipping subject to stock. Need to light a classified area? Add it to your order now.

Frequently asked questions about the LED Floodlight ATEX 200W

Which ATEX zones is it certified for? Zones 1, 2 (gas) and 21, 22 (dust).

Which traditional floodlight does it replace? 400-500W metal-halide floodlights.

Is it dimmable? No, it runs at a fixed 200W.

Which chip and driver does it use? Lumileds 3030 chip and Mean Well driver.

What warranty does it have? 5 years, with ATEX and RoHS certification.
