LED Module 50W DOB MAGNUM OSRAM SMD 3030-3D 180Lm/W 90° IP67
€21.34
Taxes not included
Color temperature
Neutral white - 4000K
Are you a professional? Sign up and enjoy special conditions. Learn more
DOCUMENTS
- Guaranteed Lowest Price
- Free shipping on orders over €299
- 100% Secure Payment Methods
- Up to 5 years warranty
The LED Module 50W DOB MAGNUM OSRAM SMD 3030-3D with 90° beam is a high-performance optical component designed to integrate into street lights, floodlights and industrial luminaires. Its design allows renewing existing installations with advanced LED technology.
72 OSRAM SMD 3030-3D triple-core diodes
It includes 72 OSRAM SMD 3030-3D triple-core diodes with luminous efficiency up to 180Lm/W, providing intense, stable flux with good colour rendering.
Integrated DOB technology
The DOB (Driver On Board) technology incorporates the driver directly on the LED board, eliminating external equipment and improving reliability.
IP67 protection
The IP67 rating protects the module against dust and temporary water immersion, ensuring safe operation outdoors under rain and humidity.
90° beam for wide coverage
The 90° angle distributes light evenly, ideal for urban lighting and wide areas.
Optimised heat dissipation
Excellent heat dissipation extends LED lifespan and maintains light performance over time.
Recommended applications
Ideal for street lights, LED floodlights, industrial warehouses and urban luminaires needing renewal or expansion.
| REFERENCE | 4835mg50w90dob |
|---|---|
| Nominal power | 50w |
| Nominal voltage | 175-265v |
| Light temperature | 4000k-5000k |
| CRI - Index Chromatic Reproduction | 84 |
| Energy class | To ++ |
| Light-lm | 7000 |
| Type of LED | 72 Diodes SMD 3030 3D (3 Corel) Osram Chip OS-Core Sapphire ODB2235S.A |
| Angle opening (º) | 90 ° |
| Efficacy LED diode (LM / W) | 180 LM / W |
| Luminous efficacy (LM / W) | 140 LM / W |
| Certificates | CE - RoHS |
| Ip | Ip67-outside |
| Estimated Life LED Diode (H) | 50.000 |
| Measures (mm) | 350mm x 75mm x 30mm |
| Power factor (PF) | 0,91 |
| Work frequency (Hz) | 50 / 60hz |
| Temperature range (ºC) | -15º + 70 ° |
| Lit cycles | 100.000 |
| Start time (s) | 0,2s |
| Additional information | Double-driver |
| Impact protection (IK) | Ik10 |
| Driver included | Dob Gxtronic Electric |
| Guarantee years | 5 |
